1SDA120717R1 | ABB E-KIT

Supply voltage AC 50 Hz

- - -V

Supply voltage AC 60 Hz

- - -V

Supply voltage DC

24.4 - 28.8V

Voltage type of supply voltage

DC

Number of relay outputs

0

Max. number of time switches

0

Model

Modular

Processing time (1K, binary operation)

0.00002ms

Number of HW-interfaces industrial Ethernet

2

Number of interfaces PROFINET

0

Number of HW-interfaces RS-232

0

Number of HW-interfaces RS-422

0

Number of HW-interfaces RS-485

1

Number of HW-interfaces USB

0

Number of HW-interfaces parallel

0

Number of HW-interfaces Wireless

0

Number of HW-interfaces other

0

Number of analogue outputs

0

Number of analogue inputs

0

Number of digital inputs

0

Number of digital outputs

0

With optical interface

No

Supporting protocol for TCP/IP

Yes

Supporting protocol for PROFIBUS

No

Supporting protocol for CAN

No

Supporting protocol for EtherCAT

No

Supporting protocol for INTERBUS

No

Supporting protocol for ASI

No

Supporting protocol for KNX

No

Supporting protocol for Modbus

Yes

Supporting protocol for Data-Highway

No

Supporting protocol for DeviceNet

No

Supporting protocol for SUCONET

No

Supporting protocol for LON

No

Supporting protocol for PROFINET IO

No

Supporting protocol for PROFINET CBA

No

Supporting protocol for SERCOS

No

Supporting protocol for Foundation Fieldbus

No

Supporting protocol for EtherNet/IP

No

Supporting protocol for AS-Interface Safety at Work

No

Supporting protocol for DeviceNet Safety

No

Supporting protocol for INTERBUS-Safety

No

Supporting protocol for PROFIsafe

No

Supporting protocol for SafetyBUS p

No

Supporting protocol for other bus systems

No

Supporting protocol for DNP3

No

Supporting protocol for IEC 60870

No

Supporting protocol for IEC 61850 Ethernet

No

Radio standard Bluetooth

No

Radio standard Wi-Fi 802.11

No

Radio standard GPRS

No

Radio standard GSM

No

Radio standard UMTS

No

Long-Term Evolution (LTE)

No

IO link master

No

System accessory

No

Redundancy

No

With display

Yes

Type of memory

RAM

Memory size

39256kByte

Additional program memory possible

No

Rail mounting possible

Yes

Wall mounting/direct mounting

No

Front built-in possible

No

Rack-assembly possible

No

Suitable for safety functions

No

SIL according to IEC 61508

None

Performance level according to EN ISO 13849-1

None

Appendant operation agent (Ex ia)

No

Appendant operation agent (Ex ib)

No

Explosion safety category for gas

None

Explosion safety category for dust

None

Certified for UL hazardous location class I

No

Certified for UL hazardous location class II

No

Certified for UL hazardous location class III

No

Certified for UL hazardous location division 1

No

Certified for UL hazardous location division 2

No

Certified for UL hazardous location group A (acetylene)

No

Certified for UL hazardous location group B (hydrogen)

No

Certified for UL hazardous location group C (ethylene)

No

Certified for UL hazardous location group D (propane)

No

Certified for UL hazardous location group E (metal dusts)

No

Certified for UL hazardous location group F (carbonaceous dusts)

No

Certified for UL hazardous location group G (non-conductive dusts)

No

Width

67.5mm

Height

135mm

Depth

84.5mm
