1SCA142587R1001 | OTA200P3B

Code: 1982658

ManufacturerRAZNO
Catalog number1SCA142587R1001
Type
EAN code6417019701226

Details

  • Low-voltage industrial components
  • Switch disconnector (low voltage)
  • 1 KOM
  • ABB

Technical specifications

Version as maintenance-/service switch

Yes

Version as reversing switch

No

Rated operating voltage

1000 - 1000V

Version as safety switch

Yes

Rated permanent current at AC-21, 400 V

-A

Rated short-time withstand current lcw

8kA

Version as emergency stop installation

No

Rated operation power at AC-3, 400 V

-kW

Number of switches

1

Switching power at 400 V

110kW

Conditioned rated short-circuit current Iq

-kA

Rated operation power at AC-23, 400 V

110kW

Max. rated operation voltage Ue AC

1000V

Version as main switch

Yes

Rated permanent current at AC-23, 400 V

200A

Rated permanent current Iu

200A

Suitable for front mounting 4-hole

No

Suitable for floor mounting

No

Number of poles

3

Voltage release optional

No

Suitable for distribution board installation

Yes

Number of auxiliary contacts as normally closed contact

2

Suitable for intermediate mounting

No

Number of auxiliary contacts as change-over contact

0

Number of auxiliary contacts as normally open contact

2

Colour control element

Black

Suitable for front mounting centre

No

Interlockable

Yes

Type of control element

Long turning handle

Motor drive optional

No

Device construction

Complete device in housing

Motor drive integrated

No

Degree of protection (IP), front side

IP65

With pre-assembled cabling

No

Degree of protection (NEMA)

Other

Width

485mm

Width in number of modular spacings

-

Height

682mm

Depth

162mm


Warehouse states

Zagreb:

0 pcs

Zadar:

0 pcs


From same serie
