Main Product Image

1SCA128486R1001 | OT3200E12P

Code: 1982608

ManufacturerRAZNO
Catalog number1SCA128486R1001
Type
EAN code6417019582740

Details

  • Low-voltage industrial components
  • Switch disconnector (low voltage)
  • 1 KOM
  • ABB

Technical specifications

Version as main switch

Yes

Version as maintenance-/service switch

Yes

Version as reversing switch

No

Version as emergency stop installation

No

Number of switches

1

Rated operating voltage

1000 - 1000V

Max. rated operation voltage Ue AC

1000V

Rated permanent current Iu

-A

Rated operation power at AC-3, 400 V

-kW

Rated permanent current at AC-23, 400 V

-A

Conditioned rated short-circuit current Iq

-kA

Rated permanent current at AC-21, 400 V

-A

Switching power at 400 V

-kW

Rated short-time withstand current lcw

65kA

Rated operation power at AC-23, 400 V

-kW

Version as safety switch

No

Device construction

Complete device in housing

Suitable for front mounting 4-hole

No

Suitable for intermediate mounting

No

Suitable for front mounting centre

No

Suitable for distribution board installation

Yes

Suitable for floor mounting

No

Voltage release optional

No

Interlockable

No

Type of electrical connection of main circuit

Bolt connection

With pre-assembled cabling

No

Colour control element

Black

Degree of protection (IP), front side

IP00

Number of auxiliary contacts as normally closed contact

0

Type of control element

Long turning handle

Motor drive optional

No

Motor drive integrated

No

Width

514mm

Number of auxiliary contacts as normally open contact

0

Number of auxiliary contacts as change-over contact

0

Degree of protection (NEMA)

Other

Number of poles

3

Height

410mm

Width in number of modular spacings

-

Depth

146mm


Warehouse states

Zagreb:

0 pcs

Zadar:

0 pcs
