1SCA022874R3060 | OT200U40C

Code: 1981916

ManufacturerRAZNO
Catalog number1SCA022874R3060
Type
EAN code6417019340197

Details

  • Low-voltage industrial components
  • Switch disconnector (low voltage)
  • 1 KOM
  • ABB

Technical specifications

Number of switches

1

Version as main switch

Yes

Rated operation power at AC-3, 400 V

-kW

Version as reversing switch

No

Version as safety switch

No

Version as emergency stop installation

No

Rated operating voltage

1000 - 1000V

Version as maintenance-/service switch

Yes

Rated operation power at AC-23, 400 V

-kW

Rated permanent current at AC-23, 400 V

200A

Switching power at 400 V

-kW

Rated short-time withstand current lcw

8kA

Conditioned rated short-circuit current Iq

-kA

Rated permanent current at AC-21, 400 V

200A

Max. rated operation voltage Ue AC

1000V

Rated permanent current Iu

-A

Number of auxiliary contacts as normally closed contact

0

Device construction

Built-in device plug-in technique

Number of poles

4

Number of auxiliary contacts as normally open contact

0

Interlockable

Yes

Motor drive integrated

No

Suitable for intermediate mounting

No

Degree of protection (IP), front side

IP20

Number of auxiliary contacts as change-over contact

0

With pre-assembled cabling

No

Type of electrical connection of main circuit

Screw connection

Type of control element

Other

Motor drive optional

No

Colour control element

Black

Voltage release optional

No

Suitable for front mounting 4-hole

Yes

Suitable for front mounting centre

No

Width

237mm

Suitable for distribution board installation

Yes

Suitable for floor mounting

No

Degree of protection (NEMA)

1

Width in number of modular spacings

-

Height

150mm

Depth

160mm


Warehouse states

Zagreb:

0 pcs

Zadar:

0 pcs


From same serie
