Main Product Image

1SCA022753R4870 | OT630E22P

Code: 1981711

ManufacturerRAZNO
Catalog number1SCA022753R4870
Type
EAN code6417019245089

Details

  • Low-voltage industrial components
  • Switch disconnector (low voltage)
  • 1 KOM
  • ABB

Technical specifications

Version as main switch

Yes

Version as reversing switch

No

Number of switches

1

Max. rated operation voltage Ue AC

1000V

Rated operating voltage

1000 - 1000V

Rated permanent current Iu

630A

Version as emergency stop installation

No

Rated permanent current at AC-21, 400 V

630A

Rated operation power at AC-23, 400 V

355kW

Rated short-time withstand current lcw

20kA

Rated permanent current at AC-23, 400 V

630A

Version as maintenance-/service switch

Yes

Rated operation power at AC-3, 400 V

-kW

Version as safety switch

No

Switching power at 400 V

355kW

Conditioned rated short-circuit current Iq

80kA

Number of poles

4

Suitable for front mounting 4-hole

No

Suitable for front mounting centre

No

Suitable for intermediate mounting

No

Suitable for distribution board installation

Yes

Number of auxiliary contacts as change-over contact

0

Colour control element

Black

Number of auxiliary contacts as normally closed contact

0

Interlockable

No

Motor drive integrated

No

Suitable for floor mounting

No

Type of electrical connection of main circuit

Bolt connection

Number of auxiliary contacts as normally open contact

0

Type of control element

Long turning handle

Degree of protection (IP), front side

IP00

Motor drive optional

No

Voltage release optional

No

With pre-assembled cabling

No

Degree of protection (NEMA)

Other

Width

331mm

Device construction

Complete device in housing

Width in number of modular spacings

-

Height

250mm

Depth

140mm


Warehouse states

Zagreb:

0 pcs

Zadar:

0 pcs
