MV92296
Code: 1975732
Details
- Luminaires
- High bay luminaire
- 1 KOM
- GEWISS
Technical specifications
Mounting method
Pendant
With light source
Yes
Lamp type
LED not exchangeable
Material housing
Plastic
Suitable for auxiliary lamp
No
Suitable for number of lamps
1
Voltage type
AC
Lamp holder
None
Colour housing
Grey
Nominal current
330 - 330mA
Dimming 1-10 V
No
Nominal voltage
220 - 240V
Dimming DALI
Yes
With control gear
Yes
Exchangeable control gear
Yes
Type of control gear
LED operating device current-controlled
Dimming 0-10 V
No
Dimming phase cut-off
No
Dimming DMX
No
Dimming LineSwitch
No
Dimming manufacturer's proprietary system
No
Dimming phase cut-on
No
Dimming Touch and Dim
No
Dimming programmable
No
Dimming DSI
No
Dimming mains voltage modulation
No
Reflector colour
Silver
No dim function
No
Dimming Zigbee
No
Dimming Sine Wave Reduction
No
Dimming RF
No
Light sharing
Symmetric
Dimming potentiometer (integrated)
No
Reflector
High-gloss
Light distributor
Refractor lens
Dimming with push-button
No
Failure rate at median useful life of 100,000 hrs at 25 °C ambient (tq)
10%
Material reflector
Plastic
Colour consistency (McAdam ellipse)
SDCM3
Beam angle
Extreme wide beam >80°
Degree of protection (IP)
IP66
Impact strength
IK08
Ball-proof
No
Lumen maintenance at median useful life of 100,000 hr at 25 °C ambient (tq)
90%
Emergency power supply integrated
No
Luminaire with limited surface temperature, sign "D“
Yes
Rated ambient temperature according to IEC62722-2-1
-30 - 50°C
Protection class
I
Suitable for emergency lighting
No
Filament test according to IEC 60695-2-11
850 °C - 30 s
Rated luminous flux according to IEC 62722-2-1
9500lm
Max. system power
64W
Colour of light
White
Colour temperature
3000 - 3000K
Colour rendering index CRI
80-89
Luminaire efficacy
148lm/W
Power factor
0.9
Photobiological safety according to EN 62471
RG0
Constant light output (CLO)
No
Colour temperature adjustable
No
Beam angle adjustable
No
Luminous flux adjustable
Continuously variable
Width
253mm
Height/depth
113mm
Length
383mm
Type of wiring
Through wiring included
Number of poles
5
Conductor cross section
1.5mm²
Connection type
Push-in clamp
With protective cover
Yes
Max. number of luminaires per miniature circuit breaker B16
10
Operation by Bluetooth
No
Max. number of luminaires per miniature circuit breaker C16
17
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
