Details
- Luminaires
- Luminaire for streets and places
- 1 KOM
- GEWISS
Technical specifications
Mounting method
Post top
Colour of light
White
Colour housing
Grey
Type of control gear
LED operating device current-controlled
Lamp holder
None
Material housing
Aluminium
Colour temperature
4000 - 4000K
Colour rendering index CRI
70-79
Width
330mm
Height/depth
215mm
Power factor
0.9
Material cover
Glass structured
Dimming DSI
No
Nominal current
1000 - 1000mA
Dimming DALI
No
Nominal voltage
220 - 240V
Dimming manufacturer's proprietary system
No
Dimming 0-10 V
No
Dimming potentiometer (integrated)
No
Dimming DMX
No
Dimming Zigbee
No
With control gear
Yes
Voltage type
AC
Exchangeable control gear
Yes
No dim function
No
Surface protection
Powder coating
Dimming mains voltage modulation
No
Degree of protection (IP)
IP66
Colour consistency (McAdam ellipse)
SDCM5
Dimming programmable
No
Dimming Sine Wave Reduction
No
Dimming LineSwitch
No
Protection class
II
Dimming phase cut-on
No
Adjustable optics
No
Dimming Touch and Dim
No
Impact strength
IK08
Dimming with push-button
No
Dimming phase cut-off
No
Luminaire efficacy
135lm/W
Suitable for spigot size
42 - 76mm
With connection cable
No
Dimming 1-10 V
Yes
Luminaire with limited surface temperature, sign "D“
No
Dimming RF
No
Rated ambient temperature according to IEC62722-2-1
-25 - 40°C
Remote control
None
Lamp type
LED not exchangeable
Length
560mm
Type of wiring
Ending
Number of poles
2
Conductor cross section
2.5mm²
Compatible with Apple HomeKit
No
Compatible with Google Assistant
No
Connection type
Screwed terminal
Compatible with Amazon Alexa
No
IFTTT support available
No
Operation by Bluetooth
No
Type of connection for sensor/communication module
Other
With light sensor
No
Suitable for number of lamps
1
With light source
Yes
With radio control
No
With light regulation program control
No
Light distributor
Reflector
Rated luminous flux according to IEC 62722-2-1
5000lm
Constant light output (CLO)
No
Max. system power
37W
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
