Details
- Domestic switching devices
- Socket outlet
- 1 KOM
- HAGER
Technical specifications
Rated fault current
-mA
Depth of device
41.6mm
Number of active pins (round)
2
With signal lamp
No
Number of socket outlets switchable
0
Connection type
Screwed terminal
With hinged lid
No
Number of active pins (flat)
0
With enhanced contact protection
Yes
RAL-number (similar)
6029
Colour
Green
Imprint/indication
None
Metallic colour
No
Number of phases
1
Number of units
1
Number of modules (module system)
1
Model
Earthing pin
Transparent
No
Label space/information surface
No
Lockable
No
Fault current protection
No
Mounting method
Flush mounted (plaster)
Over voltage protection
No
Insulated mounting
Yes
Eject-mechanism
No
With orientation lighting
No
With function lighting
No
Type of fastening
Mounting with claw and screw
Special power supply
Safety power supply (green)
Halogen free
Yes
Material
Plastic
Anti-bacterial treatment
No
With on/off switch
No
With miniature fuse
No
Material quality
Thermoplastic
Surface finishing
Matt
Surface protection
Untreated
Impact strength
IK05
Suitable for degree of protection (IP)
IP20
Frequency
50 - 60Hz
Rotated central insert
No
Height of device
71mm
With loop through function
No
Nominal voltage
250V
Width of device
71mm
Compatible with Google Assistant
No
Compatible with Apple HomeKit
No
Compatible with Amazon Alexa
No
Nominal current
16A
Min. depth of built-in installation box
31mm
For heavy conditions (according to VDE)
No
IFTTT support available
No
