Details
- Programmable logic controllers PLC
- Graphic panel
- 1 KOM
- EATON
Technical specifications
Built-in depth
43.1mm
Degree of protection (IP), front side
IP65
Supporting protocol for SERCOS
No
Supporting protocol for Modbus
Yes
Supporting protocol for SUCONET
No
Supporting protocol for Foundation Fieldbus
No
Supporting protocol for DeviceNet Safety
No
Supporting protocol for EtherNet/IP
Yes
Supporting protocol for LON
No
Supporting protocol for DeviceNet
No
Supporting protocol for INTERBUS-Safety
No
Supporting protocol for PROFINET CBA
No
Supporting protocol for PROFIsafe
No
Supporting protocol for ASI
No
Operating temperature
0 - 50°C
Supporting protocol for TCP/IP
Yes
Supporting protocol for PROFIBUS
No
Supporting protocol for PROFINET IO
No
Supporting protocol for Data-Highway
No
Supporting protocol for INTERBUS
No
Supporting protocol for other bus systems
No
Number of HW-interfaces RS-422
0
Number of HW-interfaces parallel
0
Number of HW-interfaces RS-232
1
Number of HW-interfaces RS-485
1
Number of HW-interfaces USB
2
Number of interfaces PROFINET
0
Number of HW-interfaces industrial Ethernet
2
Number of HW-interfaces other
1
Suitable for safety functions
No
Supporting protocol for CAN
Yes
Supporting protocol for AS-Interface Safety at Work
No
Supporting protocol for SafetyBUS p
No
Supporting protocol for KNX
No
Number of HW-interfaces serial TTY
0
Degree of protection (NEMA), front side
12
Voltage type of supply voltage
DC
Supply voltage DC
19.2 - 30V
Supply voltage AC 50 Hz
0 - 0V
Supply voltage AC 60 Hz
0 - 0V
Radio standard GSM
No
Wall mounting/direct mounting
No
Radio standard UMTS
No
Radio standard GPRS
No
Radio standard Bluetooth
No
Radio standard Wi-Fi 802.11
No
IO link master
No
Number of HW-interfaces Wireless
0
Rail mounting possible
No
Screen diagonal
7inch
Width of the front
404mm
Height of the front
255mm
Type of display
TFT
Number of pixels, horizontal
1024
Number of pixels, vertical
600
Number of system buttons
1
Number of buttons with LED
0
With numeric keyboard
No
With message system (incl. buffer and confirmation)
Yes
Process default value (input) possible
Yes
With alpha numeric keyboard
No
Process value representation (output) possible
Yes
With message indication
Yes
With recipes
Yes
With printer output
Yes
Useful project memory/user memory
512000kByte
Number of online languages
100
Number of password levels
200
With colour display
Yes
Number of colours of the display
16777216
Number of function buttons, programmable
0
Number of grey-scales/blue-scales of display
0
With SW interfaces
Yes
Additional software components, loadable
Yes
Touch technology
Capacitive multitouch
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
