Version as safety switch

No

Version as main switch

No

Version as maintenance-/service switch

No

Number of switches

1

Version as emergency stop installation

No

Version as reversing switch

No

Max. rated operation voltage Ue AC

690V

Rated permanent current at AC-21, 400 V

20A

Rated permanent current Iu

20A

Rated operating voltage

690 - 690V

Rated permanent current at AC-23, 400 V

13.3A

Rated operation power at AC-3, 400 V

5.5kW

Rated operation power at AC-23, 400 V

5.5kW

Rated short-time withstand current lcw

0.32kA

Switching power at 400 V

5.5kW

Conditioned rated short-circuit current Iq

6kA

Number of poles

3

Number of auxiliary contacts as normally closed contact

0

Number of auxiliary contacts as change-over contact

0

Number of auxiliary contacts as normally open contact

1

Motor drive optional

No

Motor drive integrated

No

Voltage release optional

No

Suitable for floor mounting

Yes

Device construction

Complete device in housing

Suitable for front mounting centre

No

Suitable for front mounting 4-hole

No

Suitable for distribution board installation

No

Suitable for intermediate mounting

No

Colour control element

Black

Type of control element

Short thumb-grip

Interlockable

No

With pre-assembled cabling

No

Degree of protection (IP), front side

IP65

Type of electrical connection of main circuit

Screw connection

Degree of protection (NEMA)

12

Width

150mm

Depth

200mm

Height

127mm
