Main Product Image

EMS2-ROSF-Z-3-24VDC

Code: 1862899

ManufacturerRAZNO
Catalog number192399
Type
EAN code4015081930968

Details

  • Low-voltage industrial components
  • Motor starter/motor starter combination
  • 1 KOM
  • EATON

Technical specifications

With short-circuit release

No

Type of motor starter

Reversing starter

Rated control supply voltage Us at DC

24 - 24V

Voltage type for actuating

DC

Rated control supply voltage Us at AC 50HZ

0 - 0V

Rated control supply voltage Us at AC 60HZ

0 - 0V

Rated operation current Ie

3A

Rated power, 460 V, 60 Hz, 3-phase

0kW

Overload release current setting

0.18 - 3A

Rated power, 575 V, 60 Hz, 3-phase

0kW

Rated conditional short-circuit current, type 1, 480 Y/277 V

0A

Rated operation current at AC-3, 400 V

3A

Rated operation power at AC-3, 400 V

1.1kW

Rated conditional short-circuit current, type 1, 600 Y/347 V

0A

Number of auxiliary contacts as normally closed contact

1

Rated operation power at AC-3, 230 V, 3-phase

0.55kW

Rated conditional short-circuit current, type 2, 400 V

0A

Rated conditional short-circuit current, type 2, 230 V

0A

Number of auxiliary contacts as normally open contact

1

Type of electrical connection of main circuit

Screw connection

Power consumption

3.5W

Temperature compensated overload protection

Yes

Release class

CLASS 10

Type of electrical connection for auxiliary- and control current circuit

Screw connection

Rail mounting possible

Yes

Ambient temperature, upper operating limit

70°C

Coordination class according to IEC 60947-4-3

Class 2

With transformer

No

Degree of protection (IP)

IP20

Number of command positions

0

External reset possible

No

Supporting protocol for Modbus

No

Suitable for emergency stop

No

Supporting protocol for ASI

No

Supporting protocol for PROFIBUS

No

Number of indicator lights

0

With fuse

Yes

Supporting protocol for INTERBUS

No

Degree of protection (NEMA)

Other

Supporting protocol for CAN

No

Supporting protocol for Data-Highway

No

Supporting protocol for PROFINET CBA

No

Supporting protocol for LON

No

Supporting protocol for TCP/IP

No

Supporting protocol for SERCOS

No

Supporting protocol for SUCONET

No

Supporting protocol for PROFINET IO

No

Supporting protocol for DeviceNet

No

Supporting protocol for Foundation Fieldbus

No

Supporting protocol for EtherNet/IP

No

Supporting protocol for AS-Interface Safety at Work

No

Supporting protocol for DeviceNet Safety

No

Supporting protocol for INTERBUS-Safety

No

Supporting protocol for PROFIsafe

No

Supporting protocol for SafetyBUS p

No

Supporting protocol for other bus systems

No

Width

22.5mm

Height

160mm

Depth

114.5mm
