1SCA150945R1001 | OXB800E3X4QB

Rated permanent current Iu

-A

Rated operation power at AC-3, 400 V

-kW

Conditioned rated short-circuit current Iq

-kA

Rated operating voltage

- - -V

Rated permanent current at AC-21, 400 V

-A

Switching power at 400 V

-kW

Rated operation power at AC-23, 400 V

-kW

Rated permanent current at AC-23, 400 V

-A

Number of auxiliary contacts as normally open contact

0

Number of auxiliary contacts as change-over contact

0

Number of auxiliary contacts as normally closed contact

0

Version as main switch

Yes

Version as safety switch

No

Version as emergency stop installation

No

Version as maintenance-/service switch

Yes

Rated short-time withstand current lcw

42kA

Number of switches

1

Number of poles

3

Device construction

Built-in device plug-in technique

Motor drive integrated

Yes

Suitable for front mounting 4-hole

Yes

Suitable for front mounting centre

No

Voltage release optional

No

Motor drive optional

No

Degree of protection (IP), front side

IP20

Suitable for distribution board installation

Yes

Suitable for floor mounting

No

Degree of protection (NEMA)

1

Suitable for intermediate mounting

No

Type of electrical connection of main circuit

Bolt connection

Interlockable

No

Max. rated operation voltage Ue AC

480V

Type of control element

Long turning handle

Version as reversing switch

No
