Type of control element

Long turning handle

Number of poles

4

Number of auxiliary contacts as normally closed contact

2

Number of auxiliary contacts as normally open contact

2

Rated permanent current Iu

400A

Motor drive integrated

No

Number of auxiliary contacts as change-over contact

0

Type of electrical connection of main circuit

Bolt connection

Motor drive optional

No

Device construction

Built-in device fixed built-in technique

Suitable for floor mounting

No

Suitable for intermediate mounting

No

Suitable for distribution board installation

Yes

Degree of protection (IP), front side

IP2X

Rated operation power at AC-3, 400 V

-kW

Rated operating voltage

400 - 1000V

Conditioned rated short-circuit current Iq

12kA

Max. rated operation voltage Ue AC

800V

Version as reversing switch

Yes

Rated permanent current at AC-21, 400 V

400A

Voltage release optional

No

Suitable for front mounting 4-hole

No

Version as maintenance-/service switch

Yes

Interlockable

No

Switching power at 400 V

-kW

Number of switches

-

Colour control element

Black

Rated operation power at AC-23, 400 V

125kW

Rated short-time withstand current lcw

13kA

Suitable for front mounting centre

No

Version as main switch

Yes

Version as emergency stop installation

No

Version as safety switch

Yes

Rated permanent current at AC-23, 400 V

-A
