408986 | AUT.OSIG. DX3 3P B3 16KA
Code: 1778337
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
34,47 €
Neto34,47 €
RP43,09 €
DetailsWarehouse statesTechnical specifications
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- LEGRAND
Technical specifications
Degree of protection (IP)
IP20
Voltage type
AC
Built-in depth
44mm
Suitable for flush-mounted installation
Yes
Rated voltage
400V
Width in number of modular spacings
3
Rated current
3A
Release characteristic
B
Ambient temperature during operating
-25 - 70°C
Number of protected poles
3
Connectable conductor cross section multi-wired
1.5 - 25mm²
Connectable conductor cross section solid-core
1.5 - 35mm²
Rated impulse withstand voltage Uimp
4kV
Number of poles (total)
3
Rated insulation voltage Ui
500V
Current limiting class
3
Additional equipment possible
Yes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
32kA
Pollution degree
2
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
16kA
Over voltage category
-
Frequency
50 - 60Hz
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
16kA
Concurrently switching neutral conductor
No
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
