Main Product Image

080188 | BATIBOX 1-ST 80MM FI, 50MM DUB

Code: 1776077

ManufacturerRAZNO
Catalog number080188
Type
EAN code3245060801885

Details

  • Connection devices
  • Box/housing for built-in mounting in the wall/ceiling
  • 10 KOM
  • LEGRAND

Technical specifications

Degree of protection (IP)

IP20

Width

83mm

Model

Single

Surface protection

Untreated

Halogen free

Yes

Mounting method

Other

Material

Plastic

Colour

Orange

Length

83mm

Construction type

Device connection box (round/square)

Cover model

None

Internal depth

48mm

Diameter

80mm

Shape

Round

Circuit integrity

None

Sealable

No

Suitable for cable diameter

20 - 25mm

With screening

No

Max. conductor cross section

0mm²

Number of inlets

4

Equipped with

None

Cover attachment

Other

Inlet from the rear

No

With screws

Yes

Transparent cover

No

For tube diameter

20/25 mm

Connectable

No

With nail lugs

No

Air tight

No

Nozzle

None

Pipe locking

No

Depth

- - -mm

Luminaire hook mounting

No

Housing feed-through by step membrane

No

Housing feed-through by seal membrane

No

Provided with revolving ring

No

Housing feed-through by nozzle

No

Housing feed-through by break-out opening

No

Number of included spouts

-

Pipe locking optional

No

For number of electric fittings

1

Clamp position fixed

No

Mounting switching equipment

Screw or spread out

Number of poles of the clamp

0


Warehouse states

Zagreb:

9 pcs

Zadar:

0 pcs
