HAB404

Version as emergency stop installation

No

Max. rated operation voltage Ue AC

415V

Rated permanent current Iu

40A

Rated short-time withstand current lcw

1.26kA

Rated operating voltage

380 - 415V

Rated permanent current at AC-23, 400 V

40A

Version as maintenance-/service switch

Yes

Number of switches

1

Rated permanent current at AC-21, 400 V

40A

Version as reversing switch

No

Version as safety switch

Yes

Version as main switch

Yes

Rated operation power at AC-23, 400 V

18kW

Switching power at 400 V

26kW

Number of auxiliary contacts as normally closed contact

0

Number of poles

4

Conditioned rated short-circuit current Iq

50kA

Number of auxiliary contacts as change-over contact

0

Motor drive optional

No

Voltage release optional

No

Device construction

Built-in device fixed built-in technique

Suitable for front mounting centre

No

Suitable for front mounting 4-hole

No

Suitable for intermediate mounting

No

Type of control element

Short thumb-grip

Colour control element

Grey

Interlockable

Yes

Suitable for floor mounting

Yes

Number of auxiliary contacts as normally open contact

0

Degree of protection (IP), front side

IP20

With pre-assembled cabling

No

Degree of protection (NEMA)

Other

Width

60mm

Height

68mm

Motor drive integrated

No

Suitable for distribution board installation

Yes

Type of electrical connection of main circuit

Screw connection

Width in number of modular spacings

3.5

Depth

69mm
