Type of control element

Push button

Number of poles

4

Number of auxiliary contacts as normally closed contact

0

Number of auxiliary contacts as normally open contact

0

Rated permanent current Iu

2500A

Motor drive integrated

No

Type of electrical connection of main circuit

Rail connection

Motor drive optional

Yes

Device construction

Built-in device slide-in technique (withdrawable)

Number of auxiliary contacts as change-over contact

2

Rated operation power at AC-3, 400 V

0kW

Suitable for floor mounting

Yes

Suitable for intermediate mounting

No

Suitable for distribution board installation

Yes

Degree of protection (IP), front side

IP31

Rated short-time withstand current lcw

85kA

Conditioned rated short-circuit current Iq

187kA

Rated operating voltage

690 - 690V

Max. rated operation voltage Ue AC

690V

Rated operation power at AC-23, 400 V

0kW

Version as emergency stop installation

No

Version as safety switch

No

Version as reversing switch

No

Suitable for front mounting 4-hole

No

Version as maintenance-/service switch

No

Voltage release optional

Yes

Number of switches

-

Interlockable

Yes

Switching power at 400 V

0kW

Colour control element

Green

Version as main switch

Yes

Suitable for front mounting centre

No

Rated permanent current at AC-21, 400 V

0A

Rated permanent current at AC-23, 400 V

-A
