Main Product Image

RS2-02-C3

Code: 1639039

ManufacturerRAZNO
Catalog number177286
Type
EAN code4015081717392

Details

  • Sensors
  • Position switch with separate actuator
  • 1 KOM
  • EATON

Technical specifications

Width sensor

26mm

With status indication

No

Length of sensor

52mm

Number of contacts as change-over contact

0

Suitable for safety functions

Yes

Rated operation current Ie at AC-15, 125 V

0A

Type of switching contact

Other

Number of contacts as normally closed contact

2

Number of contacts as normally open contact

0

Material housing

Plastic

Coating housing

Plastic-coated

Rated operation current Ie at AC-15, 230 V

0A

Type of electric connection

With cable preassembled

Height of sensor

13mm

Explosion safety category for gas

None

Explosion safety category for dust

None

Type of interface

None

Rated operation current Ie at DC-13, 125 V

0A

Type of interface for safety communication

None

Ambient temperature during operating

-10 - 55°C

Construction type housing

Cuboid

Rated operation current Ie at DC-13, 24 V

0.3A

Forced opening

No

Rated operation current Ie at AC-15, 24 V

0A

Degree of protection (NEMA)

Other

Rated operation current Ie at DC-13, 230 V

0A

Number of safety auxiliary contacts

2

Degree of protection (IP)

IP67


Warehouse states

Zagreb:

0 pcs

Zadar:

0 pcs


From same serie
