Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- EATON
Technical specifications
Rated voltage
240V
Rated impulse withstand voltage Uimp
4kV
Rated insulation voltage Ui
500V
Number of poles (total)
2
Number of protected poles
1
Rated fault current
0.01A
Current limiting class
3
Rated current
4A
Leakage current type
A
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Rated short-circuit breaking capacity according to EN 61009
6kA
Release characteristic
B
Concurrently switching neutral conductor
Yes
Surge current capacity
0.25kA
Disconnection characteristic
Undelayed
Width in number of modular spacings
2
Anti-nuisance tripping version
No
Built-in depth
75.5mm
Frequency
50 Hz
Ambient temperature during operating
-25 - 40°C
Connectable conductor cross section solid-core
1 - 25mm²
Degree of protection (IP)
IP20
Connectable conductor cross section multi-wired
1 - 25mm²
Over voltage category
3
Rated short-circuit breaking capacity Icn according to EN 61009-1
6kA
With interlocking device
No
Flush-mounted installation
No
Voltage type
AC
Pollution degree
2
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
FRBm6-B4/1N/001-A
Details
- Circuit breakers and fuses
- Earth leakage circuit breaker
- 1 KOM
- EATON
DetailsWarehouse statesTechnical specifications
Technical specifications
Rated voltage
240V
Rated impulse withstand voltage Uimp
4kV
Rated insulation voltage Ui
500V
Number of poles (total)
2
Number of protected poles
1
Rated fault current
0.01A
Current limiting class
3
Rated current
4A
Leakage current type
A
Rated short-circuit breaking capacity according to IEC 60947-2
0kA
Rated short-circuit breaking capacity according to EN 61009
6kA
Release characteristic
B
Concurrently switching neutral conductor
Surge current capacity
0.25kA
Disconnection characteristic
Undelayed
Width in number of modular spacings
2
Anti-nuisance tripping version
Built-in depth
75.5mm
Frequency
50 Hz
Ambient temperature during operating
-25 .. 40°C
Connectable conductor cross section solid-core
1 .. 25mm²
Degree of protection (IP)
IP20
Connectable conductor cross section multi-wired
1 .. 25mm²
Over voltage category
3
Rated short-circuit breaking capacity Icn according to EN 61009-1
6kA
With interlocking device
Flush-mounted installation
Voltage type
AC
Pollution degree
2
From same serie
