2CDS273001R0024 | S203M-C2
Code: 1549963
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
34,02 €
Neto34,02 €
RP42,53 €
DetailsWarehouse statesTechnical specifications
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- ABB
Technical specifications
Release characteristic
C
Number of poles (total)
3
Rated voltage
400V
Rated impulse withstand voltage Uimp
4kV
Rated insulation voltage Ui
440V
Frequency
50 - 60Hz
Current limiting class
3
Number of protected poles
3
Connectable conductor cross section multi-wired
0 - 25mm²
Rated current
2A
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
25kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Voltage type
AC/DC
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
15kA
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Width in number of modular spacings
3
Additional equipment possible
Yes
Degree of protection (IP)
IP20
Concurrently switching neutral conductor
No
Suitable for flush-mounted installation
No
Over voltage category
3
Built-in depth
69mm
Ambient temperature during operating
-25 - 55°C
Pollution degree
3
Connectable conductor cross section solid-core
0 - 35mm²
Power loss
5.4W
Flush-mounted installation
No
Explosion-proof
No
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
