1SCA100858R1001 | OS630D03N3P
Code: 1524603
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
1.190,99 €
Neto1.190,99 €
RP1.488,74 €
DetailsWarehouse statesTechnical specifications
Details
- Low-voltage industrial components
- Fuse switch disconnector
- 1 KOM
- ABB
Technical specifications
Number of poles
3
Type of control element
Long turning handle
Rated permanent current Iu
570A
Motor drive optional
No
Motor drive integrated
No
Type of electrical connection of main circuit
Bolt connection
Suitable for floor mounting
No
Max. rated operation voltage Ue AC
1000V
Version as main switch
Yes
Conditioned rated short-circuit current Iq
80kA
Rated short-time withstand current lcw
18kA
Cable entry
Other
Rated operation power at AC-23, 400 V
630kW
Version as emergency stop installation
No
Version as safety switch
Yes
Suitable for front mounting
No
With error protection
No
Suitable for busbar mounting
Yes
Suitable for fuses
NH3
Position control element
Left
Equipped with connectors
Yes
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
*VPC is wholesale amount without VAT (tax on added value). For wholesale discounts, please register as business user.
