1SCA022785R4270 | OT800E03C
Code: 1523978
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
1.175,63 €
Neto1.175,63 €
RP1.469,54 €
DetailsWarehouse statesTechnical specifications
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
Technical specifications
Rated permanent current Iu
-A
Rated operation power at AC-3, 400 V
-kW
Conditioned rated short-circuit current Iq
-kA
Version as main switch
Yes
Version as maintenance-/service switch
Yes
Version as safety switch
No
Version as emergency stop installation
No
Version as reversing switch
No
Number of switches
1
Max. rated operation voltage Ue AC
1000V
Rated operating voltage
1000 - 1000V
Rated permanent current at AC-23, 400 V
800A
Rated permanent current at AC-21, 400 V
800A
Rated short-time withstand current lcw
20kA
Rated operation power at AC-23, 400 V
450kW
Switching power at 400 V
450kW
Number of poles
3
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as normally closed contact
0
Motor drive optional
No
Motor drive integrated
No
Voltage release optional
No
Device construction
Built-in device plug-in technique
Suitable for floor mounting
No
Suitable for front mounting 4-hole
Yes
Suitable for front mounting centre
No
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Colour control element
Black
Type of control element
Other
Interlockable
Yes
With pre-assembled cabling
No
Degree of protection (IP), front side
IP20
Depth
280mm
Width
311mm
Degree of protection (NEMA)
1
Height
250mm
Width in number of modular spacings
-
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
