DILMF8-01(RAC48)

Voltage type for actuating

AC

Number of normally open contacts as main contact

3

Rated control supply voltage Us at AC 50HZ

42 - 48V

Rated control supply voltage Us at AC 60HZ

42 - 48V

Type of electrical connection of main circuit

Screw connection

Operating voltage at AC 60 Hz

230 - 690V

Rated operation current Ie at AC-3, 400 V

7A

Rated operation power NEMA

7.4kW

Height

85mm

Rated operation current Ie at AC-4, 400 V

5A

Rated operation current Ie at AC-1, 400 V

20A

Number of auxiliary contacts as normally open contact

0

Width

45mm

Rated control supply voltage Us at DC

0 - 0V

Rated operation power at AC-4, 400 V

2.2kW

Operating voltage at AC 50 Hz

230 - 690V

Number of normally closed contacts as main contact

0

Rated operation power at AC-3, 400 V

3kW

Modular version

No

Depth

97mm

Number of auxiliary contacts as normally closed contact

1
