FAZ-C4/2

Number of poles (total)

2

Rated current

4A

Flush-mounted installation

No

Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V

10kA

Voltage type

AC

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V

15kA

Frequency

50 - 60Hz

Ambient temperature during operating

-25 - 75°C

Additional equipment possible

Yes

Release characteristic

C

Connectable conductor cross section solid-core

1 - 25mm²

Pollution degree

2

Width in number of modular spacings

2

Over voltage category

3

Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V

15kA

Rated impulse withstand voltage Uimp

4kV

Power loss

3W

Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V

10kA

Degree of protection (IP)

IP20

Built-in depth

70.5mm

Explosion-proof

No

Concurrently switching neutral conductor

No

Current limiting class

3

Rated voltage

400V

Rated insulation voltage Ui

440V

Connectable conductor cross section multi-wired

1 - 25mm²

Number of protected poles

2
