Number of poles

16

Type of control element

Door coupling rotary drive

Rated permanent current Iu

63A

Number of auxiliary contacts as normally open contact

0

Number of auxiliary contacts as normally closed contact

0

Motor drive integrated

No

Motor drive optional

No

Type of electrical connection of main circuit

Screw connection

Device construction

Built-in device fixed built-in technique

Number of auxiliary contacts as change-over contact

0

Rated operation power at AC-3, 400 V

22kW

Degree of protection (IP), front side

IP65

Degree of protection (NEMA)

12

Suitable for floor mounting

Yes

Suitable for intermediate mounting

Yes

Suitable for distribution board installation

No

Max. rated operation voltage Ue AC

690V

Conditioned rated short-circuit current Iq

2kA

Rated operating voltage

690 - 690V

Rated short-time withstand current lcw

1.3kA

Suitable for front mounting 4-hole

No

Version as reversing switch

No

Rated permanent current at AC-21, 400 V

63A

Voltage release optional

No

Interlockable

Yes

Version as maintenance-/service switch

Yes

Rated permanent current at AC-23, 400 V

63A

Rated operation power at AC-23, 400 V

30kW

Suitable for front mounting centre

No

Version as emergency stop installation

Yes

Colour control element

Red

Version as safety switch

No

Switching power at 400 V

30kW

Number of switches

1

Version as main switch

Yes
