Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- EATON
Technical specifications
Degree of protection (IP)
IP20
Voltage type
AC
Suitable for flush-mounted installation
No
Built-in depth
70.5mm
Rated voltage
400V
Rated current
10A
Width in number of modular spacings
3
Ambient temperature during operating
-25 - 75°C
Release characteristic
C
Connectable conductor cross section multi-wired
1 - 25mm²
Connectable conductor cross section solid-core
1 - 25mm²
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
6kA
Number of protected poles
3
Rated impulse withstand voltage Uimp
4kV
Rated insulation voltage Ui
440V
Over voltage category
3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
0kA
Number of poles (total)
3
Current limiting class
3
Additional equipment possible
Yes
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
0kA
Pollution degree
2
Frequency
50 - 60Hz
Concurrently switching neutral conductor
No
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
6kA
Warehouse states
Zagreb:
13 pcs
Zadar:
5 pcs
