PL7-B6/3
Code: 1015337
In stock 1 pcs
Zagreb1 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
Possible delivery within 24h
WSP*
23,96 €
Neto23,96 €
RP29,95 €
DetailsWarehouse statesTechnical specificationsFrom same serie
Details
- Circuit breakers and fuses
- Miniature circuit breaker (MCB)
- 1 KOM
- EATON
Technical specifications
Degree of protection (IP)
IP20
Voltage type
AC
Built-in depth
70.5mm
Suitable for flush-mounted installation
No
Rated current
6A
Rated voltage
400V
Width in number of modular spacings
3
Release characteristic
B
Ambient temperature during operating
-25 - 75°C
Rated short-circuit breaking capacity Icn according to EN 60898 at 230 V
10kA
Connectable conductor cross section multi-wired
1 - 25mm²
Number of protected poles
3
Connectable conductor cross section solid-core
1 - 25mm²
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 400 V
0kA
Over voltage category
3
Rated impulse withstand voltage Uimp
4kV
Number of poles (total)
3
Rated insulation voltage Ui
440V
Current limiting class
3
Rated short-circuit breaking capacity Icu according to IEC 60947-2 at 230 V
0kA
Additional equipment possible
Yes
Frequency
50 - 60Hz
Concurrently switching neutral conductor
No
Pollution degree
2
Rated short-circuit breaking capacity Icn according to EN 60898 at 400 V
10kA
Warehouse states
Zagreb:
1 pcs
Zadar:
0 pcs
From same serie
