1SDA079651R1 | E4.2V-A/MS 3200 4p WMP
Code: 1985714
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
16.724,52 €
Neto16.724,52 €
RP20.905,65 €
DetailsWarehouse statesTechnical specifications
Details
- Low-voltage industrial components
- Switch disconnector
- 1 KOM
- ABB
Technical specifications
Version as main switch
Yes
Version as maintenance-/service switch
No
Version as safety switch
No
Version as emergency stop installation
No
Version as reversing switch
No
Number of switches
0
Max. rated operation voltage Ue AC
600V
Rated operating voltage
600 - 600V
Rated permanent current Iu
3200A
Rated permanent current at AC-23, 400 V
3200A
Rated permanent current at AC-21, 400 V
3200A
Rated operation power at AC-3, 400 V
-kW
Rated short-time withstand current lcw
85kA
Switching power at 400 V
-kW
Conditioned rated short-circuit current Iq
-kA
Rated operation power at AC-23, 400 V
-kW
Number of poles
4
Number of auxiliary contacts as normally closed contact
0
Number of auxiliary contacts as change-over contact
0
Number of auxiliary contacts as normally open contact
0
Motor drive optional
Yes
Motor drive integrated
No
Voltage release optional
Yes
Device construction
Built-in device slide-in technique (withdrawable)
Suitable for floor mounting
No
Suitable for front mounting 4-hole
No
Suitable for front mounting centre
No
Suitable for distribution board installation
Yes
Suitable for intermediate mounting
No
Colour control element
Other
Type of control element
Push button
Interlockable
Yes
With pre-assembled cabling
No
Type of electrical connection of main circuit
Bolt connection
Degree of protection (IP), front side
IP30
Width
551mm
Height
425mm
Degree of protection (NEMA)
Other
Depth
393mm
Width in number of modular spacings
-
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
