1SCA022809R9110 | OT400E12W
Code: 1981814
Order only
Zagreb0 pcs
Zadar0 pcs
Sign in or create an account for lower prices and other benefits
WSP*
197,01 €
Neto197,01 €
RP246,26 €
DetailsWarehouse statesTechnical specifications
Details
- Low-voltage industrial components
- Switch disconnector (low voltage)
- 1 KOM
- ABB
Technical specifications
Max. rated operation voltage Ue AC
1000V
Rated permanent current Iu
400A
Version as safety switch
No
Rated operation power at AC-3, 400 V
-kW
Version as maintenance-/service switch
Yes
Number of switches
1
Version as emergency stop installation
No
Version as reversing switch
No
Rated short-time withstand current lcw
15kA
Version as main switch
Yes
Conditioned rated short-circuit current Iq
-kA
Rated operating voltage
1000 - 1000V
Switching power at 400 V
230kW
Rated permanent current at AC-23, 400 V
400A
Rated permanent current at AC-21, 400 V
400A
Rated operation power at AC-23, 400 V
230kW
Number of auxiliary contacts as normally open contact
0
Number of auxiliary contacts as change-over contact
0
Number of poles
3
Number of auxiliary contacts as normally closed contact
0
Motor drive optional
No
Motor drive integrated
No
Suitable for floor mounting
No
Voltage release optional
No
Device construction
Complete device in housing
Suitable for intermediate mounting
No
Suitable for front mounting 4-hole
No
Interlockable
No
Degree of protection (IP), front side
IP00
Type of electrical connection of main circuit
Bolt connection
Suitable for distribution board installation
Yes
Type of control element
Other
Suitable for front mounting centre
No
With pre-assembled cabling
No
Degree of protection (NEMA)
Other
Width
221mm
Depth
105mm
Width in number of modular spacings
-
Height
220mm
Warehouse states
Zagreb:
0 pcs
Zadar:
0 pcs
From same serie
